Diesel Forklift Model CPCD

Diesel Forklift Model CPCD

Product Abstract:

Diesel Forklift with Low Maintenance


Product Description

Diesel Forklift CPCD



1 Model   CPCD80
2 Power type   Diesel
3 Rated capacity  kg 8000
4 Load center mm 600
5 Operator type   Drive in seat
SIZE
6 Max. lift height of mast with Load-backrest  mm 4380
7 Max.lift height of fork(standard) mm 3000
8 Mast lift  height of fork(standard) mm 2500
9 Free lift height(standard) mm 205
10 Height of load-backrest mm 1372
11 Distance from seat to overhead guard   mm 1045
12 Overhead guard height   mm 2450
13 Length (without fork) mm 3600
14 Front overhang mm 590
15 Rear overhang mm 760
16 Wheel base mm 2250
17 The height of traction pin mm 395
18 Min. ground clearance mm 200
19 Overall width mm 1995
20 Distance between forks(Max/Min)   mm 1840/300
21 Tread(front /rear)   mm 1470/1700
22 Min. Turning radius(outside) mm 3370
23 Min. Turning radius(outside) mm 210
24 Min. Intersecting aisle   mm 3060
25 Mast tilt angle deg 6° / 12°
26 Fork size mm 1220X150X75
PERFORMANCE
27
Speeds
Max.Drive speeds(with/withoutload) km/h 26/28
28 Lifting speeds (with load) mm/s 480
29 Lowering speeds(without /with load) mm/s ≤600 / ≥300
30 Max.tracking force (with/without full load) KN 65
31 Max.grade ability (with/without full load) % 28/18
WEIGHT
32 Total weight kg 9850
33 Weight distribution full load (front/rear) kg 14880/1970
34 Weight distribution zero load (front/rear) kg 4070/5800
WHEELS AND TYRES
35 Quantity of wheels   4 X / 2
37 Type of tyres   Pneumatic tyres
38 Tyres Front   8.25-15-14PR
39 Rear   8.25-15-14PR
40 Driving brake   Hydraumatic Pedal
41 Parking brake   Mechanical Manual
42 Number of speeds for transmission 2-2 Power shift transimission
