16m Scissor Lift Table

16m Scissor Lift Table

Product Abstract:

QYCY0.5-16


Product Description

16m Scissor Lift Table



No.

Name

Spec

1

Platform

3mm flat plate

2

Scissor structure

160*100*6mm   steel tube  Q345

3

Chassis

160*80*5mm steel tube

4

    Rails

5mm folded steel plate´╝înylon sliding block

5

Cylinder

HSG90/60   *4  Explosion proof & leaking valve

6

Oil pipe

2-10-43MPa high strength pressure oil pipe

7

Pump

Emergency valve with manual operator

8

Power

3kw/380v/50hz

9

Tyre

700-9        air fill *4

10

Leg

160*80*5mm  steel tube

11

Switch box

Delixi

12

Control

Up & Down with over charge protection

13

Travel switch

High quality

14

Pin

45#  steel bar

15

Oil

32# hydraulic oil

16

Lifting

4-6m / min

17

Polishing

100% 3d Blasting grinding

18

Paint

Electrostatic powder coating
